SF-1W Lead Free Thrust Bearings Oil Free Environmental protection Round punched

Place of Origin China
Brand Name CCVK
Certification ISO9001
Model Number SF-1W
Minimum Order Quantity 10000peice
Price negotiable
Packaging Details Export carton; Wooden case ; Wood pallet.
Delivery Time 2~4 Weeks
Payment Terms L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability 1000000 Piece/Pieces per Month Bearing Bush
Product Details
Lubricating Lead-free Bearing Internal Treatment Environmental Protection
Working Temperature -195℃~+280℃ Size 0406~300100
Application Automobile Shock Absorber, Motorcycle Shock Absorber, Hydraulic Cylinder, Hydraulic Motor, Pneumatic Components Max Load Capacity 140N/mm2
Type Sleeve, Flange, Washer, Strip
High Light

Lead Free Thrust Bearings


Toyota Vios Auto Part DX Bearing

Leave a Message
Product Description

SF-1W Lead-free Thrust bearings ,oil-free bushing for toyota vios auto part

Sf-1W lead-free bearing is a new product developed based on SF-1X material according to international environmental requirements.

The product is widely used in general machinery, especially for food machinery, pharmaceutical machinery, tobacco machinery, lead free effect in line with European environmental protection requirements, is the development direction of oil-free lubricated bearings.

Maximum bearing pressure: 140N/mm2

Friction coefficient μ : 0.04~0.20

Applicable temperature range: -195℃~280℃

Maximum sliding speed: 5m/s

Maximum PV value (dry) : 3.6N/mm2. M /s

Maximum allowed PV value (oil) : 50N/mm2. M /s


Sleeve Bearings:
Model No. Min.I.D. Min.O.D. Max.I.D. Max.O.D. Max.Length
DU,SF-1 6mm 8mm 300mm 305mm 100mm
DX,SF-2 10mm 12mm 300mm 305mm 100mm
JF800 10mm 12mm 173mm 180mm 100mm
FB090 10mm 12mm 300mm 305mm 100mm
FB092 10mm 12mm 300mm 305mm 100mm
JDB,JCB 8mm 12mm 160mm 180mm 150mm
FU 1.5mm 3mm 50mm 70mm 70mm
JGB 1.5mm 3mm 300mm 320mm 100mm


Flange Bearings:
Model No. Min.I.D. Min.O.D. Max.I.D. Max.O.D. Min.F.D. Max.F.D. Max.Length
DU,SF-1 6mm 8mm 40mm 44mm 12mm 53mm 40mm
JF800 40mm 46mm 95mm 105mm 60mm 144mm 127mm
FB090 25mm 28mm 300mm 305mm 35mm 340mm 90mm
FB092 25mm 28mm 300mm 305mm 35mm 340mm 90mm
JDB 10mm 14mm 120mm 140mm 22mm 170mm 100mm
FU 6mm 12mm 50mm 60mm 14mm 70mm 70mm
JGB 6mm 12mm 300mm 320mm 35mm 340mm 130mm



Technical Data
Performance index Data
Max Load Capacity Static load 250N/mm²
Dynamic load 140N/mm²
Max Sliding Speed Dry friction 2.5m/s
Oil lubrication 5.0m/s
Max PV Value Limit Dry friction 3.6N/mm².m/s
Oil lubrication 50N/mm².m/s
Friction coefficient Dry friction 0.08-0.20
Oil lubrication 0.02-0.07
Working temperature -195℃~+280℃
Thermal conductivity 42W/m.k
Coefficient of thermal expansion 11*10-5/k

SF-1W Lead Free Thrust Bearings Oil Free Environmental protection Round punched 0
